48kW Hybrid Solar System Product Detailed Description:
Our 48kW UL Hybrid PV + ESS System is designed for businesses seeking energy independence and cost savings. Key features include:
- High-Efficiency Solar Panels: 450Wp monocrystalline bifacial modules for superior energy harvest.
- Hybrid Inverter (48kW): Dual MPPT trackers, 3-phase output (200-240V), and high conversion efficiency.
- High-Voltage Lithium Battery (34kWh): Long lifespan and fast charging for reliable backup power.
- Durable Mounting System: Aluminum alloy brackets for rooftop or ground installation.
- Smart Energy Management: Optional diesel generator support and remote monitoring capabilities.
Ideal for: Factories, warehouses, office buildings, and other energy-intensive commercial applications.
Technical Specifications Table:
| Component | Specifications |
|---|---|
| Hybrid Inverter | 48kW, 3-phase (200-240V), 90%+ efficiency, dual MPPT |
| Solar Panels | 450Wp, monocrystalline bifacial, 1720x1140x30mm, 28.5kg per panel |
| Battery Storage | 34kWh, HV lithium, 437V/250Ah, 0.31-55°C operating range |
| Operating Temperature | -40°C to 90°C, UL-certified |
| Backup Power | Supports critical loads during grid outages |
| Daily Energy Output | 318-336kWh (solar) + 34kWh (battery backup) |
| Certifications | UL, CE, IEC |
