The UE Solar EMT Pro Series represents the cutting edge of off-ogrid inverter technology, combining robust power delivery with intelligent energy management. These 8.5KW and 11KW models are engineered for demanding off-grid solar applications where reliability and flexibility are paramount.
Next-Generation Features:
- Intelligent Power Routing 🧠
The revolutionary dual output design automatically prioritizes loads and manages power distribution between solar, battery, and grid sources. Critical circuits stay powered during outages while non-essential loads can be shed automatically. - High Voltage Advantage ⚡
With an exceptional 60-500V DC input range, these inverters accommodate both residential and commercial solar array configurations without requiring additional transformers or boost converters. - Visual System Intelligence 💡
The integrated RGB status lighting provides instant visual feedback on system status, battery levels, and power flow - no need to check monitoring screens for basic operation. - Ultra-Wide Compatibility 🔄
Designed to work seamlessly with lithium batteries (including 48V systems), lead-acid, and emerging battery technologies. The advanced CCCV charging algorithm extends battery life by up to 30%.
Ideal For:
- Off-grid homes and cabins
- Off-grid solar systems
- Telecom installations
- Agricultural applications
- 紧急备用系统
- Microgrid implementations
技术规格
| 参数 | EM8500T-48L | EM11000T-48L |
| 交流输出 | ||
| 额定功率 | 8,500W | 11,000W |
| Apparent Power | 17,500VA | 25,000VA |
| 电压 | 220V/230VAC | |
| 频率 | 50Hz/60Hz (Auto-sensing) | |
| 波形 | 纯正弦波 | |
| DC Input | ||
| Voltage Range | 60-500VDC | |
| MPPT 跟踪器 | 2 | 2 |
| Max PV Input | 8,000W | 11,000W |
| 电池 | ||
| 电压 | 48VDC | |
| Max Discharge Current | 300A | 320A |
| Charging Method | CCCV | |
| 效率 | ||
| Peak | 97% | 97% |
| Physical | ||
| 尺寸（毫米） | 500×400×102 | 550×800×112 |
| 重量 | 14.5kg | 16kg |
| Environmental | ||
| 工作温度 | -10°C to +90°C | -10°C to +90°C |
