Product Description
The UE SPI-8K-UP and SPI-10K-UP are powerful 48V hybrid inverters tailored for off-grid living, rural properties, and backup power systems in the US. Featuring UL1741 and FCC Class B certifications, they are fully compliant with North American electrical standards.
Each unit delivers clean pure sine wave output at 120/240V, supporting all common household appliances and even motor loads (up to 6HP). The system supports dual MPPT inputs, enabling 11kW solar array capacity (5.5kW × 2) and wide voltage range from 125–425VDC.
With support for lithium and lead-acid batteries, the SPI-UP series offers advanced BMS communication, a 200A PV charge current, and up to 120A grid or generator charge rate – making it ideal for battery-heavy systems.
Installers can scale the system to 6 units in parallel (max 60kW) for larger estates or commercial microgrids. Its industrial design and intuitive interface make setup and maintenance fast and user-friendly.
Technical Specifications
| Model | SPI-8K-UP | SPI-10K-UP |
| Rated Output Power | 8000W | 10000W |
| Peak Output Power | 16000W | 20000W |
| Output Voltage | 120V single / 240V split-phase (support 3-phase parallel) | |
| Output Frequency | 50/60Hz (selectable) | |
| Waveform | Pure Sine Wave | |
| Switching Time | 10ms typical | |
| Parallel Units | Up to 6 | |
| Battery Voltage | 48VDC (range 40–60V) | |
| Max PV Charging Current | 180A | 200A |
| Max AC Charging Current (Grid/Gen) | 100A | 120A |
| Hybrid Charge Current Max | 180A | 200A |
| MPPT Trackers | 2 × (22A / 500V) | |
| MPPT Voltage Range | 125–425VDC | |
| Bypass Overload Current | 63A | |
| Dimensions (W × H × D) | 620 × 445 × 130 mm | |
| Weight | 27 kg | |
| Noise | <60dB | |
| Protection | IP20 (Indoor use only) | |
| Cooling | Internal Fan | |
| Communication | RS485 / CAN / USB / Dry Contact; WiFi/GPRS optional | |
| Certifications | UL1741, IEC62109, FCC Class B, EN61000-6 | |
| Warranty | 18 Months | |
