Product Description
The Deye SUN-7K~10K-SG05LP1-EU-SM2 is a high-performance single-phase hybrid inverter series tailored for solar energy storage projects across Europe. With output models from 7kW to 10kW and peak charge/discharge currents up to 210A, this inverter series enables flexible, powerful energy management for homes and small commercial facilities.
It supports both lithium and lead-acid batteries, diesel generator integration, and AC coupling for existing PV upgrades. The inverter features 2 MPPTs, supports 600V max PV input voltage, and can be paralleled with up to 16 units. With its IP65 outdoor protection, silent cooling, and color touch screen, it provides a seamless user experience.
Full system control is available via RS485/CAN and cloud monitoring apps. Ideal for residential grid-tied systems with battery backup or full off-grid solar+storage solutions.
Key Specifications
| Parameter | SUN-7K | SUN-7.6K | SUN-8K | SUN-10K |
| Rated Output Power (W) | 7000 | 7600 | 8000 | 10000 |
| Max. Apparent Power (VA) | 7700 | 8360 | 8800 | 11000 |
| Max. Charge/Discharge Current | 175A | 190A | 190A | 210A |
| PV Input Power (W) | 11200 | 12160 | 12800 | 16000 |
| PV Input Voltage Range (V) | 150–425V | 150–425V | 150–425V | 150–425V |
| MPPT Tracker / Strings | 2/2 | 2/2 | 2/2 | 2/2 |
| Battery Voltage Range (V) | 40–60V | 40–60V | 40–60V | 40–60V |
| AC Voltage Output | 220/230V (±15%) | 220/230V (±15%) | 220/230V (±15%) | 220/230V (±15%) |
| Max. Efficiency / Euro | 97.6% / 96.5% | 97.6% / 96.5% | 97.6% / 96.5% | 97.6% / 96.5% |
| IP Rating | IP65 | IP65 | IP65 | IP65 |
| Cooling Method | Smart air cooling | Smart air cooling | Smart air cooling | Smart air cooling |
| Communication Ports | RS485 / CAN / WiFi / 4G / GPRS / LAN | |||
| Parallel Operation | Up to 16 inverters | |||
| Dimensions (mm) | 366×589.5×237 | 366×589.5×237 | 366×589.5×237 | 366×589.5×237 |
| Weight (kg) | 26.8 | 26.8 | 26.8 | 26.8 |
