Product Detailed Description:
The UE 8kW Split-Phase System is engineered for US energy needs:
Key Components:
- Solar Panels:
- 500W HJT bifacial modules (220×115×5cm, 15kg) – high efficiency in low light.
- Hybrid Inverter:
- 8kW split-phase output (120V/240V, 60Hz), 158-420V MPPT range.
- Battery Storage:
- 15kWh LiFePO4 (3.2V/100Ah cells, modular expandability).
- Accessories:
- Aluminum roof mounts, AC/DC disconnects, and NEC-compliant wiring.
Performance Highlights:
- Daily Generation: 32–48kWh (4-6 sun hours).
- Backup Power: 14.6kWh (runs essentials overnight).
- Certifications: CE, IEC, UL9540 (pending).
Technical Specifications Table:
| Component | Specifications |
|---|---|
| Solar Panel | 500W HJT bifacial, 220×115×5cm |
| Inverter | 8kW split-phase, 98% efficiency, dual MPPT |
| Battery | 15kWh LiFePO4 (40V/100Ah modules) |
| MPPT Range | 158-420V DC |
| Operating Temp | -4°F to 122°F (battery), -40°F to 140°F (panel) |
| Communication | WiFi/App monitoring |
