540W Solar Panel Product Detailed Description
The UNI H 540W HJT Panel redefines rooftop solar performance with:
- Heterojunction (HJT) Technology: Lower energy loss and higher efficiency (up to 24.2%) in low-light or high-heat conditions.
- Bifacial Excellence: 90% bifaciality factor boosts output by harvesting reflected light (e.g., from white roofs).
- Premium Build: Double-glass (2.0mm/1.6mm) + PIB edge sealing for 30+ year lifespan.
- Aesthetic Appeal: All-black design blends seamlessly with residential and commercial rooftops.
- Rigorous Certifications: Complies with IEC 61215, IEC 61730, UL 61730, and ISO 9001/14001/45001.
Perfect for:
- Homeowners seeking high-efficiency, long-lasting solar.
- Businesses prioritizing aesthetics + ROI.
- Architects integrating solar into building designs.
Technical Specifications Table:
| Category | Specifications |
|---|---|
| Maximum Power (Pmax) | 520–540W (STC), up to 585W with bifacial gain |
| Efficiency | Up to 24.2% (STC) |
| Dimensions | 1960×1134×30mm, 27.1kg |
| Bifaciality | 90% (industry-leading) |
| Frame | Anodized black aluminum alloy |
| Operating Temperature | -40°C to +85°C |
| Warranty | 15-year materials + 30-year 88% power output |
| Certifications | IEC 61215, IEC 61730, UL 61730, ISO 9001/14001/45001 |
