520W Solar Panel Product Detailed Description
The UNI 530W N-Type TOPCon Solar Panel combines cutting-edge technology with robust engineering for high ROI energy projects:
- N-Type TOPCon Cells: MBB (Multi-Busbar) design reduces resistance and boosts efficiency.
- Bifacial Dual Glass: 2.0mm/1.6mm tempered glass enhances durability and rear-side gains.
- Harsh Environment Proof: Passes salt spray, ammonia corrosion, and mechanical stress tests (TUV Nord).
- Smart Compatibility: 1500V system voltage and 4mm² output cables for flexible installations.
- Certified Quality: Complies with IEC 61215, IEC 61730, UL 61730, and ISO standards.
Ideal for:
- Large-scale solar farms
- Industrial rooftops
- High-snow/wind regions
Technical Specifications Table
| Category | Specifications |
|---|---|
| Maximum Power (Pmax) | 510–530W (STC), up to 597W with 10% bifacial gain |
| Efficiency | Up to 23.85% (STC) |
| Dimensions | 1961×1134×30mm, 27.7kg |
| Frame Material | Anodized aluminum alloy |
| Operating Temperature | -40°C to +85°C |
| Bifacial Gain | 5–25% additional output |
| Certifications | IEC 61215, IEC 61730, UL 61730, ISO 9001/14001/45001 |
