Detailed Product Description
The SPI H3P Series represents the pinnacle of three-phase off-grid power conversion technology, delivering industrial-grade performance for mission-critical applications. These 8KW to 12KW inverters are engineered to power commercial facilities, agricultural operations, and remote industrial sites where reliable three-phase power is essential.
Industrial Power Features:
- Balanced Three-Phase Output ⚡
Delivering true 230/400V three-phase power, the H3P series can run heavy machinery, commercial HVAC systems, and manufacturing equipment with perfect voltage balance across all phases. The <3% THD ensures clean power for sensitive CNC equipment and medical devices. - Military-Grade Charging System 🔋
The industry-leading 260A charging current (with generator input) means you can recharge massive battery banks up to 40% faster than competing models - crucial for operations with limited generator fuel or runtime windows. - Extreme Environment Ready ❄️🔥
Operating from -25°C to +60°C with intelligent thermal management, these inverters perform reliably in freezing cold storage facilities, scorching industrial plants, or dusty agricultural environments. - Smart Energy Management 🧠
The exclusive time-slot function automatically optimizes energy usage based on your schedule, while the dual BMS activation ensures perfect communication with lithium battery systems for maximum performance and lifespan.
Ideal Applications:
- Manufacturing facilities
- Agricultural operations (pumping, cooling)
- Remote mining/oilfield sites
- Telecommunications hubs
- Cold storage warehouses
- Water treatment plants
- Microgrid implementations
- EV charging stations
Technical Specifications
| Parameter | SPI-8K-H3P | SPI-10K-H3P | SPI-12K-H3P |
| AC Output | |||
| Rated Power | 8,000W | 10,000W | 12,000W |
| Peak Power | 16,000VA | 20,000VA | 24,000VA |
| Voltage | 230/400V three-phase | ||
| Frequency | 50/60Hz | ||
| Waveform | Pure Sine Wave | ||
| Motor Start | 6HP | ||
| Battery | |||
| Type | Li-ion/Lead-acid/User-defined | ||
| Voltage | 400VDC | ||
| Max Charge Current (MPPT) | 200A | 220A | 260A |
| Max Charge Current (Generator) | 260A | ||
| PV Input | |||
| MPPT Trackers | 2 independent | ||
| Max Input Power | 8,000W + 8,000W | 10,000W + 10,000W | 12,000W + 12,000W |
| Operating Voltage | 200-650VDC | ||
| Efficiency | |||
| MPPT Tracking | 99.90% | ||
| Peak Inverter | 97.50% | ||
| General | |||
| Dimensions | 700*400*300mm | ||
| Weight | 32kg | ||
| Protection | IP65 | ||
| Operating Temp | -25℃ to +60℃ | ||
| Warranty | 5 years | ||
